Pentek Introduces Rugged and Light-weight Portable Talon RF/IF Signal Recorder

  • Digitizes up to four channels of analog RF/IF signals at 500 MS/sec
  • Built-in digital down-conversion with programmable bandwidth
  • Real-time aggregate recording rates up to 4.0 GB/s
  • SSD RAID storage capacity up to 30.7 TB using NTFS files
  • SystemFlow GUI control panel for fast, intuitive operation
Follow Us On Facebook
Follow Us On LinkedIn
Follow Us On Twitter
Follow Us On Google+
Follow Us On YouTube

Upper Saddle River, NJ - November 28, 2016 - Today announced a new member of its popular family of Talon® RF/IF signal recording and playback systems. The Model RTR 2727A rugged portable recorder targets applications needing to record and reproduce high-bandwidth signals. A complete PC workstation, the RTR 2727A provides high data capacity and aggregate recording rates of up to 4.0 GB/s in a four-channel system.

The RTR 2727A offers up to sixteen hot-swap solid state drives (SSDs) with a combined capacity to 30.7 TB sustain hours of continuous recording. The system features recording and playback of RF/IF signal frequencies up to 700 MHz with signal bandwidths up to 200 MHz. Available data converters include 500 MHz 12-bit A/Ds or 400 MHz 14-bit A/Ds and 800 MHz 16-bit D/As.

At the heart of the RTR 2727A are Pentek Cobalt® Series Virtex-6 software radio boards featuring A/D and D/A converters, DDCs (digital downconverters), DUCs (digital upconverters), and complementary FPGA IP cores. Optional GPS time and position stamping allows the user to record this critical signal information.

"The RTR 2727A offers nearly ten times the storage capacity of its predecessor in a 25% smaller package. Its SSDs, highly resistant to shock and vibration, and its optional DC power supply support operational environments for aircraft, ships, and vehicles," said Rodger Hosking, vice-president of Pentek. "This portable instrument is ideal for IF/RF signal recording and playback in radar, communications and other high frequency applications."

Rugged Construction

The RTR 2727A is housed in a rugged, lightweight chassis measuring only 16.0" W x 6.9" D x 13.0" H and weighing less than 30 pounds. This extremely portable workstation features 100% aluminum alloy construction, reinforced with shock absorbing rubber corners and an impact-resistant protective glass for the high resolution 17" LCD monitor.

The hot-swappable SSD array is available in configurations from 1.9 TB to 30.7 TB and supports RAID levels 0, 1, 5, or 6. The SSDs are meticulously qualified by Pentek for optimum use in rugged and portable applications. By using hot swappable solid-state drives, the recorders exhibit high immunity to shock and vibration for ground vehicles, ships and aircraft.

Available I/O includes VGA video, six USB 2.0 ports, two USB 3.0 ports and dual Gigabit Ethernet connections.

Ease of Operation

All Talon RTR Portable Recorders are built on a Windows 7 Professional workstation with an Intel Core i7 processor and provide both a GUI (graphical user interface) and API (Application Programmers Interface) to control the system. Systems are fully supported with Pentek's SystemFlow software for system control and turn-key operation. The software provides a GUI with point-and-click configuration management and storage of custom configurations for single-click setup. The software also includes a virtual oscilloscope and signal analyzer to monitor signals before, during and after data collection.

Available Options, Evaluation Package and Pricing

The RTR 2727A offers an optional GPS receiver that allows users to time stamp recordings as well as store GPS position information. Other options include an 18 to 36 VDC power supply and a removable operating system drive.

Pentek's SystemFlow Simulator software package, available for download for free, simulates the SystemFlow recording software, which is installed on all Talon recording systems. The simulator allows users to operate the standard GUI and the SystemFlow API. The free trial package is available for download here.

Pricing and Availability

For the latest pricing, delivery and available options, please fill out this form and your request will be delivered to the appropriate department. To learn more about our products or to discuss your specific application please email our sales department at sales@pentek.com, contact your local representative or Pentek directly:

Mario Schiavone
Sales Director
Pentek, Inc.
One Park Way
Upper Saddle River, NJ 07458
USA
Tel: +1 (201) 818-5900
Fax: +1 (201) 818-5904
sales@pentek.com
Map + Directions

Product Detail

Photos and Attachments



Media contact:
Barbara Stewart, Patterson & Associates
39810 N 105th Way, Scottsdale, AZ 85262
Tel: +1 (480) 488-6909
Email: barbara@patterson.com
