Pentek designs embedded computer boards and recording systems for DSP, software radio and data acquisition as an ISO 9001:2008 certified company. Products feature high-speed digital and analog interfaces and FPGAs in AMC, XMC, FMC, PMC, cPCI, PCIe, and VPX form factors suitable for both COTS and rugged environments.

Evolutionary Jade Architecture with Xilinx Kintex UltraScale FPGA
JadeTM 4-Channel 200 MHz A/D with DDC, Kintex UltraScale FPGA
Model 71861 4-Channel 200 MHz A/D with DDC, Kintex UltraScale FPGA
Jade Model 71861

  • Complete radar and software radio interface solution
  • Supports Xilinx Kintex UltraScale FPGAs
  • Four 200 MHz 16-bit A/Ds
  • Four multiband DDCs (digital downconverters)
  • Optional 5 GB of DDR4 SDRAM
  • Sample clock synchronization to an external system reference
  • LVPECL clock/sync bus for multimodule synchronization
  • PCI Express (Gen. 1, 2 & 3) interface up to x8
  • VITA 42.0 XMC compatible with switched fabric interfaces
  • Optional LVDS and gigabit serial connections to the FPGA for custom I/O
  • Ruggedized and conduction-cooled versions available
Navigator Design Suite compatible with Xilinx's Vivado IP Integrator
NavigatorTM was designed to work with new JadeTM architecture
Navigator Design Suite
Navigator DS

Pentek's Navigator Design Suite includes:

New Series of Sentinel Intelligent Signal Scanning Recorders
Talon® 6 GHz RF/IF Sentinel Intelligent Signal Scanning Recorder
RTS 2620 Talon 6 GHz RF/IF Sentinel Intelligent Signal Scanning Rackmount Recorder
Model RTS 2620

  • Selectable threshold triggered or manual record modes
  • 16-bit A/D with 75 dB SNR & 87 dB SFDR
  • Built-in DDC with selectable decimation range from 2 to 65,536
  • Built-in DUC with selectable interpolation range from 2 to 65,536
